FilmTec™
High Permeability
Sea Water
8"x40"
FilmTec™ SW30HRLE-400
DuPont FilmTec™
Sea Water
99.8%
7,500 GPD
400 (37) ft2 (m2)
DuPont FilmTec™
FUNCTIONALITY:
Seawater High Permeate Quality Reverse Osmosis Membrane Element
TYPICAL PROPERTIES
Product Name
SW30HRLE-400
Application
Sea Water
Stabilized Salt Rejection (%)
99.8%
Active Area ft2 (m2)
400 (37)
Feed Spacer Thickness (mil)
28
Permeate Flow Rate gpd (m3/d)
7,500 (28)
SUGGESTED OPERATIONG CONDITIONS
Type
Polyamide Thin-Film Composite
Maximum Operating Pressure
1,200 psi (83 bar)
pH Range Short-Term Cleaning
1 - 13
Maximum Pressure
Drop Per Pressure Vessel
50 psig (3.5 bar)
Maximum Operating Temperature
113°F (45°C)
pH Range Continuous Operation
2 - 11
Maximum Pressure Drop Per Element
15 psig (1.0 bar)
Free Chlorine Tolerance
< 0.1 ppm
ELEMENT DIMENSIONS
Dimensions – inches (mm)
A 40.0 (1,016)
B 1.125 ID (29)
C 7.9 (201)
SIMILAR PROPERTIES
