FilmTec™
Residential
Tap Water
2"x12"
FilmTec™ TW30-1812-100HR
DuPont FilmTec™
Tap Water
98%
100 GPD
28 ft² (2.6 m²)
DuPont FilmTec™
FUNCTIONALITY:
FilmTec™Residential Elements are some of the most reliable, consistent and highest quality in the industry. Our 100 GPD elements offer a superior balance of the highest available flow with premium rejection, ideal for low feed pressure residential applications.
TYPICAL PROPERTIES
Product Name
TW30-1812-100HR
Application
Tap Water
Stabilized Salt Rejection (%)
98 %
Active Area ft2 (m2)
28 (2.6)
Feed Spacer Thickness (mil)
7
Permeate Flow Rate gpd (m3/d)
100 (0.378)
SUGGESTED OPERATIONG CONDITIONS
Type
Residential Reverse Osmosis Elements
Maximum Operating Pressure
150 psig (10 bar)
pH Range Short-Term Cleaning
1 - 13
Maximum Pressure
Drop Per Pressure Vessel
n/a
Maximum Operating Temperature
113°F (45°C)
pH Range Continuous Operation
2 - 11
Maximum Pressure Drop Per Element
15 psig (1.0 bar)
Free Chlorine Tolerance
< 0.1 ppm
ELEMENT DIMENSIONS
Dimensions – inches (mm)
A. 11.74(in.) 298(mm.)
B. 0.875(in.) 22.2(mm.)
C. 0.68(in.) 17(mm.)
D. 1.75(in.) 44.5(mm.)
E. 9.4(in.) 239(mm.)
